While there are various styles of heat pumps, they all operate on the same principles. A heat pump transfers heat from one location to another through a four-step process involving evaporation, compression, condensation, and expansion. The refrigeration cycle employed for heat transfer is essential for the efficiency of a heat pump.

How a Heat Pump Works: A Simplified Overview

Evaporation

Heat pumps extract heat from air, ground, or water sources. This heat is then transferred to a heat exchanger containing liquid refrigerant. The refrigerant absorbs the heat and evaporates, transforming it into a low-temperature, low-pressure gas.

Compression

The low-temperature, low-pressure gas is directed to a compressor, which increases its pressure and temperature, converting it into a high-pressure, high-temperature gas.

Condensation

Next, the heated gas moves to another heat exchanger, where a blower transfers the heat into the desired space for heating.

Expansion

After the refrigerant releases heat and cools down, it passes through an expansion valve. This valve lowers the pressure, allowing the refrigerant to absorb heat from the heat source once again. The cycle then restarts as the refrigerant is pumped back into the heat exchanger.

Heat Pump Efficiency: Understanding Their Performance

Heat pumps demonstrate significantly higher efficiency compared to other heating systems. While an electric furnace can convert 100% of its energy into heat, a fuel-based furnace, such as a gas furnace, typically achieves between 95 and 98% fuel conversion efficiency. However, heat pumps generate three to four times more heat than the energy they consume to operate, making them approximately 300% efficient. This efficiency stems from their ability to extract heat from the environment rather than rely solely on natural gas, oil, propane, or electricity.

The efficiency of heat pumps is measured by their coefficient of performance (CoP), which denotes the amount of heat produced per unit of electricity consumed. For instance, a heat pump with a CoP of 4.0 generates four units of heat for every unit of electricity it uses.

It’s important to note that the efficiency of heat pumps can vary throughout the year due to fluctuations in outdoor temperatures. While modern heat pumps are designed to function effectively even in subzero temperatures, their efficiency decreases as outdoor temperatures drop. Nonetheless, technological advancements have enhanced heat pumps’ performance, allowing them to operate efficiently in a wide range of conditions.

Understanding Your Heat Pump’s Energy Usage

Suppose you’re currently heating your home with electricity. In that case, the US Department of Energy estimates that switching to a heat pump could reduce your heating electricity consumption by up to 50%. However, suppose you’re transitioning from a combustion fuel heating system like a natural gas, oil, or propane furnace. In that case, the reduction in energy expenses will depend on the relative costs of these fuels compared to electricity in your area.

Like all heating systems, the effectiveness of your heat pump hinges on the thermal efficiency of your home or building. This means ensuring proper sealing and sufficient insulation rated for your local climate.

How Heat Pumps Heat Your Home in Cold Weather

You’re not alone if you’re puzzled about how a heat pump can operate in freezing temperatures. The following is a simple explanation.

Even when it’s cold outside, heat’s still present in the air. It’s essential to understand that when your thermostat reads 0 degrees Fahrenheit, it doesn’t mean there’s no warmth in the air. Absolute zero is -459.67 degrees Fahrenheit.

Your heat pump utilizes refrigerant running through its coils at temperatures as low as -60 degrees Fahrenheit. The heat in the air outside, even when it’s 0 degrees Fahrenheit or even colder, naturally moves toward the refrigerant in the heat pump, warming it up. Once the heat from the air transfers to the refrigerant, the compressor further heats the refrigerant using a small amount of electricity. This heat is transferred into your home, keeping you warm even in cold weather.
